Permalife EMillwork catalog 2015

304 / 465

Overall system height includes 3 7/8” space below rail, bottom rail, top rail, and baluster height.
Estimated price per foot includes top rails, bottom rails, and balusters spaced to pass 4” sphere rule.
*We will pre-assemble each section of your balustrade system for only $38.00 per lineal foot.
HAMILTONBALUSTRADE
A B C D E F G H I J K L M N
PART NUMBER
SPINDLE
WIDTH
TOP
BLOCK
HEIGHT
BOTTOM
BLOCK
HEIGHT
SPINDLE
HEIGHT
ON
CENTER
SPACING
SPINDLES
PER
FOOT
*OVERALL
SYSTEM
HEIGHT
SPINDLE
PRICE
**PRICE
PER FOOT
A
B
C
D
E
F
G
H
I
J
K
L
M
N
BAL05X28HM-A
BAL05X28HM-B
BAL05X28HM-C
BAL05X26HM-D
BAL05X26HM-E
BAL05X26HM-F
BAL05X24HM-G
BAL05X24HM-H
BAL05X24HM-I
BAL05X23HM-J
BAL05X23HM-K
BAL05X21HM-L
BAL05X21HM-M
BAL05X18HM-N
5"
5"
5"
5"
5"
5"
5"
5"
5"
5"
5"
5"
5"
5"
5" SQ
5" RD
5" RD
3" SQ
3" RD
3" RD
3" SQ
3" RD
3" RD
NONE
NONE
NONE
NONE
NONE
28"
28"
28"
26"
26"
26"
24"
24"
24"
23"
23"
21"
21"
18"
6-7/8"
6-7/8"
6-7/8"
6-7/8"
6-7/8"
6-7/8"
6-7/8"
6-7/8"
6-7/8"
6-7/8"
6-7/8"
6-7/8"
6-7/8"
6-7/8"
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
1.75
42-1/2"
42-1/2"
42-1/2"
40-1/2"
40-1/2"
40-1/2"
38-1/2"
38-1/2"
38-1/2"
37-1/2"
37-1/2"
35-1/2"
35-1/2"
32-1/2"
$96.00
$96.00
$96.00
$92.00
$92.00
$92.00
$86.00
$86.00
$86.00
$83.00
$83.00
$80.00
$80.00
$68.00
$216.56
$216.56
$216.56
$209.58
$209.58
$209.58
$199.11
$199.11
$199.11
$193.87
$193.87
$188.64
$188.64
$167.69
5" SQ
5" SQ
5" RD
5" SQ
5" SQ
5" RD
3" SQ
3" SQ
3" RD
5" SQ
5" RD
3" SQ
3" RD
NONE
