Decorative Millwork
32
STONE & TIMBER
www.permalifeinc.comPart Number
Projection (A)
Height (B)
Overall Width (C)
BMRTS4X4X24S* 24" 3 1 / 4 " 3 1 / 4 " BMRTS6X4X12S* 12" 5 1 / 4 " 3 1 / 4 " BMRTS6X4X24S* 24" 5 1 / 4 " 3 1 / 4 " BMRTS6X6X12S* 12" 5 1 / 4 " 5 1 / 4 " BMRTS6X6X24S* 24" 5 1 / 4 " 5 1 / 4 " BMRTS8X4X12S* 12" 7 1 / 4 " 3 1 / 4 " BMRTS8X4X24S* 24" 7 1 / 4 " 3 1 / 4 " BMRTS8X6X24S* 24" 7 1 / 4 " 5 1 / 4 " BMRTBN8X4X15S* 15" 8 / 12 Pitch 7 3 / 4 " 4" BMRTBN8X4X30S* 30" 7 3 / 4 " 4"Timber Rafter Tails
Stainable
Timber Rafter Tails
Double-Ended Stainable
Part Number
Projection (A)
Height (B)
Overall Width (C)
BMRTDE8X4X40S* 40" 8" 4" BMRTDE6X3X32S* BMRTDE6X4X36S* 32" 36" 6" 6" 3" 4" BMRTDE9X3X32S* 32" 9" 3" BMRTDE9X4X36S* 36" 9" 4" BMRTDE8X3X36S* 36" 8" 3" C A BC
A
B
C A B C A B C A B* Product has open cavity
* Product has open cavity
B
C
A
B
C
A
