Decorative Millwork
34
STONE & TIMBER
www.permalifeinc.comTimber Trellis System
Stainable
Trellis Kit Part Number & Contents
Overall Width (Installed)
Overall Height (Installed)
Projection (Installed)
TRLS18987 Fits 16'-18' Garage Doors (2) BKT32X31X5S, Outlooker (4) BMD4X8X144S, 12' Beam (18) FLTBA36X3X3S, Rafter Tail (1) TRLS18989, Hardware Kit 21' 9" Over 16' Door 23' 9" Over 18' Door 41 7 / 8 " 36" TRLS18988 Fits 8'-9' Garage Doors (2) BKT32X31X5S, Outlooker (2) BMD4X8X48S, 4' Beam (2) BMD4X8X144S, 12' Beam (10) FLTBA36X3X3S, Rafter Tail (1) TRLS18994, Hardware Kit 13' 9" Over 8' Door 14' 9" Over 9' Door 41 7 / 8 " 36"Individual Trellis Components
Part Number
Projection
Height
Overall Width
BKT32X31X5S Outlooker 32 1 / 2 " 30 5 / 8 " 5 1 / 4 " BMD4X8X48S^ Beam 4 1 / 4 " 7 3 / 4 " 48" BMD4X8X144S^ Beam 4 1 / 4 " 7 3 / 4 " 144" FLTBA36X3X3S^ Lattice 36" 3 1 / 2 " 2 3 / 4 " TRLS18989 Hardware Kit for TRLS18987 Kit Contains: (3) Angle Bracket (3) U Bracket (1) Screw Pack (1) Installation Guide — — TRLS18994 Hardware Kit for TRLS18988 Kit Contains: (2) Angle Bracket (2) U Bracket (1) Screw Pack (1) Installation Guide — —NOTE: See page 127 in the polyurethane catalog for smooth trellis
^ This product is not finished on all sides
NOTE: For installation instructions, please visit www.
permalifeinc .com
Scrolled profile on one end
only
Angled on one end onlyTimber Beam
Stainable
Part Number
Overall
Width (A)
Overall
Height (B)
Length (C)
Inside
Width
Inside
Height
BM4X5X192S 6 5 / 8 " 5" 16' 2 3 / 4 " 4 1 / 4 "For smooth beam options, please refer to page 133 of the polyurethane catalog.
C B A NEW
